Ebara EV-A06 Dry Rotary Lobe Vacuum Pump Solvent Vapor Trap Kit, Intake Catch Pot For Liquids, KF-40

Ebara EV-A06 Dry Rotary Lobe Vacuum Pump Solvent Vapor Trap Kit, Catch Pot For Liquids, With Sight Glass & Drain Valve
Ebara Technologies Part Number C-3080-003-3100 (FT-118)

These Ebara solvent traps are designed for the EV-A06 dry rotary lobe vacuum pumps. These catch-pot traps are used to collect liquids that are present in the vacuum line and help prevent them from entering into the vacuum pump. This kit includes the solvent trap and KF-40 vacuum fittings need to install this solvent trap onto an EV-A06 pumps (see photographs above). The solvent trap includes a quality sight glass for visual inspection and a manual drain valve with NPT pipe thread fittings. The solvent trap has Ebara Technologies part number C-3080-003-3100 (FT-118).

Specifications:

KF-40 Vacuum Flanges
Corrosive Resistant Stainless Steel
Solvent Level Sight Glass
Integrated Drain Valve
KF-40 Tee
KF-40 Full Nipple Union
KF-40 90 Degree Elbow
KF-40 Centering Rings and Clamps

Press ESC to Close

Availability Of Kit Components Kit: P106005 - Ebara EV-A06 Dry Rotary Lobe Vacuum Pump Solvent Vapor Trap Kit, Intake Catch Pot For Liquids, KF-40
Component	Desc.	Req'd	Avail
Non-Standard	No Component Description Available On Website	1	1
P101200	Hinge Clamp KF-40 Vacuum Fittings, ISO-KF Flange Size NW-40, Aluminum	4	1594
P101211	Tee KF-40 Vacuum Fittings, ISO-KF Flange Size NW-40, Stainless Steel	1	234
P101224	Elbow 90 KF-40 Vacuum Fittings, ISO-KF Flange Size NW-40, Stainless Steel	1	1005
P101244	Centering Ring KF-40 Vacuum Fittings, ISO-KF Flange Size NW-40, Stainless Steel & Viton® O-ring	4	9564
P103443	Nipple Full KF-40 Vacuum Fittings, ISO-KF Flange Size NW-40, Stainless Steel, 122 mm Long	1	27
