Condition:
  New
Part Number:
  P102943
Warranty:
  Leybold Warranty

Available Now:
3  



$1,493.85


Print Version

Leybold AK 16-25 Condensate Separator Trap, for Leybold Trivac B, D16B/BCS, D25B/BCS, P/N 18811


NEW Leybold AK 16-25 Condensate Separator Trap, for Leybold D 16B/BCS, D 25B/BCS, P/N 18811

The AK 16-25 Condensate Separator Trap is ideally suited for applications generating large quantities of water vapor or other condensibles, which could conceivably become entrained in the pump fluid. By the use of gravity this trap collects liquids and particles, preventing them from entering the pump. For use on inlets or outlets. Can be easily drained. Can be used with hydrocarbon or PFPE oil systems. For complete specifications and advantages to the user, download data sheet see below. (AVAILABLE DOWNLOADS:)

Leybold AK 16-25 Condensate Separator Trap:
Fits Pump Models: Leybold D16B, D16BCS, Leybold D25B, D25BCS
Inlet & Exhaust Flanges: ISO KF25 (NW25)
Weight: 5.3 lb


Press ESC to Close


PDF Logo Leybold AK 4-8, 16-25, 40-65 Condensate Separators Data Sheet.pdf

PDF Logo IVP Technical Considerations for Selecting Vacuum Components for Chemical Processes.pdf
