Condition:
  New
Part Number:
  S101095
Warranty:
  As-Stated*

Available Now:
31  

RoHS Compliance Sticker


$38.55


Regular Price: $51.40

On Sale Flyer
Print Version

Optical Breadboard 6 x 6 in., 0.5 in. Thick, 1/4-20 Tapped Hole Array, Anodized Aluminum.


Optical Breadboard 6 x 6 in., 0.5 in. Thick, 1/4"-20 Tapped Hole Array, Anodized Aluminum.

These non-magnetic blue-anodized optical breadboards are the perfect low-cost solutions when building small optical subassemblies. They are 1/4"-20 tapped on a 1" standard optical table breadboard pattern (the first row of holes are 0.5 inches from the edge). They have five counterbored holes, one on each corner inset 1" from the edge and one in the center, which are used with 1/4" socket head cap screws to provide a smooth top surface when mounting the breadboard to a table or adding pedestals as feet. The flatness is specified as 0.006" over 1 ft2.

  • Width = 6 in.
  • Length = 6 in.
  • Thickness = 0.5 in.
  • 1/4"-20 inch tapped on a 1" standard optical table breadboard pattern.
  • Counterbores for 1/4" socket head cap screw inset 1" on each corner and at center.


Press ESC to Close


PDF Logo RoHS Compliance Download

Ideal Spectroscopy offers 3D CAD models in Solidworks (SLDPRT), STP, & STEP formats. For those without CAD software a free trial 3D model viewer with measurement capabilities can be downloaded here:

E-drawing LogoeDrawings Viewer For Windows
E-drawing LogoeDrawings Viewer For MAC.
