Condition:
  New
Part Number:
  P1011697
Warranty:
  Against Product Defect

Available Now:
1  
Expecting:   2
Anticipated Arrival:  2 on 2024-04-28

RoHS Compliance Sticker


$907.01


Print Version

Water Reference Cell, H2O, 19 mm Diameter, 75 mm Length


Water (H2O) Reference Cell.

These flame-sealed cells contain a small amount of >98% pure water (H2O) vapor. The concentration of water in the vapor phase may be controlled by heating the cell or cooling the tipoff stem. Operating temperatures typically range from -10-100°C. Water has a strong vibrational X band absorption which is used for calibration of tunable lasers and wavelength meters in the range of 3450-4000 cm-1 (2500-2900 nm).

The quartz cell body is cylindrical in shape; outer diameter 19 mm; length 75 mm. The tipoff stem is centered on the cell, protruding not more than 10 mm from the cell body. Windows are angled 11° off of normal and have a 2° interior wedge to prevent back-reflection and etalon effects.



Press ESC to Close


PDF Logo RoHS Compliance Download

PDF Logo Ideal Vacuum Company Overview Brochure.pdf

Ideal Spectroscopy offers 3D CAD models in Solidworks (SLDPRT), STP, & STEP formats. For those without CAD software a free trial 3D model viewer with measurement capabilities can be downloaded here:

E-drawing LogoeDrawings Viewer For Windows
E-drawing LogoeDrawings Viewer For MAC.
